Stereo PA amplifier with SMPS, 2 x 850 W / 4 ohms
-Stereo PA amplifier with class D circuitry
-Low weight and height due to integrated switch mode power supply
-Reliable power amp with high impulse stability for a wide range of applications (e.g. compact PAs, multi-way PAs, concerts)
-Limiter and speaker switch-on delay
-3 operating modes can be selected (stereo, parallel or bridged)
-2 calibrated level controls for precise level adjustment
-Input sensitivity adjustable
-LED VU meter and LEDs for activated protective circuit (protect), overload (clip), and signal per channel
-Highly efficient front-to-rear air routing
-Electronically balanced inputs via XLR mounting jacks, with XLR feed-through outputs
-Speaker outputs via lockable Speaker plugs and screw terminals
-Rugged steel chassis with aluminum front panel
-Rack installation with 2 units
-Housing design: (19") 48,3 cm rack installation
-Height unit: 2 U
-Power connection: Mains Input Socket (M) P-Con (Power-In) Power supply cord with safety plug (M) (provided)

Power supply: 100-240 V AC, 50/60 Hz
Power output (RMS):
Stereo, parallel at 4 ohms 2 x 850 W
Stereo, parallel at 8 ohms 2 x 500 W
8 ohms bridged 1 x 1700 W
Signal-to-Noise ratio: >100 dB
Total harmonic distortion:
Damping factor: >500
Voltage gain: 38.2 dB
Slew rate: >10 V/µsec
Input sensitivity: 0.775 V/1.0 V/1.81 V bzw. 39.3 dB/37 dB/32 dB, switchable
Input impedance: 20 kohms (balanced), 10 kohms (unbalanced)
Input connectors: 4 x XLR
Output connectors: 4 x Speaker, 4 x XLR feed-through output
Circuitry: Class D
Protection: Softstart, short-circuit, overheat, overload, clip limit, RF and VHF signals
Cooling: 2 temperature-controlled fans, front-to-rear
Controls: Power switch, input attenuators, mode switch stereo/parallel/bridged, input sensitivity
LED indicators: protect, clip, -5 dB, -10 dB, -20 dB (per channel)
Construction: steel chassis, aluminum front
Dimensions: 483 x 307 x 89 mm
Rack installation with 2 U
Weight: 6 kg
Power consumption: 150 W 1/8 power
Frequency range: 20 - 20000 Hz
Height: 8,9 cm
Depth: 30,7 cm
Width: 48,3 cm
Power/channel (4 Ohm): 850 W
Power connection: Mains Input Socket (M) P-Con (Power-In) Power supply cord with safety plug (M)
Power supply: 110-240 V AC, 50/60 Hz
