Active Full Range Loudspeaker

filter products

Frequency response, from
55 - 55 Hz
Frequency response, to
20000 - 20000 Hz
SPL, max
128 - 128 dB
Nominal power - RMS
300 - 300 W
Nominal power - Peak
400 - 400 W
Nominal dispersion angle, horizontal
80 - 80 °
Nominal dispersion angle, vertical
40 - 40 °
CMRR
50 - 50 dB
THD
0.2 - 0.2 %
Phase Response from
750 - 750 Hz
Phase Response to
18000 - 18000 Hz
Crossover frequency
2000 - 2000 Hz
Input XLR
1 - 1 pcs
slave XLR
1 - 1 pcs
AC Volts, min
100 - 100 V
AC Volts, max
240 - 240 V
AC Frequency, min
50 - 50 Hz
AC Frequency, max
60 - 60 Hz
operating temp, max
45 - 45 °C
weight
20.87 - 20.87 kg
width
283 - 283 mm
height
570 - 570 mm
length
311 - 311 mm
low frequency transducer
1 - 1 pcs
high frequency transducer
1 - 1 pcs
Voice Coil Diameter, low frequency
10 - 10 "
Voice Coil Diameter, high frequency
3 - 3 "
Diaphragm Diameter, high frequency
3 - 3 "
