EUROLITE LED SLS-144 RGBW Floor

EUROLITE

1
2
3
4
5

Technical specifications, datasheets, descriptions and tender texts for EUROLITE LED SLS-144 RGBW Floor

Info
order code
51915280
product link
EAN
4026397555752
Product Name
EUROLITE LED SLS-144 RGBW Floor
technical overview
Power supply: 100-240 V AC, 50/60 Hz
DMX channels: 4/6
DMX connection: 3-pin XLR
Sound-control: via built-in microphone
Flashrate: 0-10 Hz
LED type: 5 mm
LED number: 144; 36 x Red, 36 x Green, 36 x Blue, 36 x White
Beam angle: 25°
Dimensions (W x D x H): 190 x 140 x 210 mm
Ecodesign regulation: Yes
Special product: Not designed for household room illumination
Purpose: Show effect lighting
IP classification: IP20
DMX channels: 4
Power consumption: 17 W
Flash rate: 1 - 10 Hz
Weight: 1 kg
Beam angle: 25°
Lamp type: LED lamp
Laser class: Without laser
Height: 21 cm
Width: 19 cm
Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M)
Depth: 14 cm
LED: 144 x 5 mm RGBW (homogenous color mix)
Power supply: 110-240 V AC, 50/60 Hz
main features
Flat spotlight with 144 LEDs in the colors red, green, blue and white
-Operable in stand-alone mode or via DMX interface
-DMX512 control possible via any commercial DMX controller (occupies max. 6 channels)
-4 or 6 DMX channels selectable for numerous applications
-Master/Slave function for synchronous operation with several devices
-Sound-control via built-in microphone
-Microphone-sensitivity adjustable
Connectors
DMX connector types
3pin
Control
control channels, min
4 ch
control channels, max
4 ch
Electrical
power consumption watt, max
17.00 W
AC Volts, min
110 V
AC Volts, max
240 V
AC Frequency, min
50 Hz
AC Frequency, max
60 Hz
IP rating
20
power input connector
IEC-60320 C13/C14
Mechanical
weight
1.00 kg
width
190.00 mm
height
210.00 mm
length
140.00 mm
Optical
beam angle/zoom, min
25.00 °
beam angle/zoom, max
25.00 °
light source
LED
Number of light sources
144 pcs
COLD WHITE LED source
yes
RED light source
yes
GREEN light source
yes
BLUE light source
yes
shutter/strobe frequency, max
10 Hz
