EUROLITE LED SLS-360 UV 36x1W Floor

EUROLITE

1
2
3
4
5

Technical specifications, datasheets, descriptions and tender texts for EUROLITE LED SLS-360 UV 36x1W Floor

Info
order code
51915289
product link
EAN
4026397599565
Product Name
EUROLITE LED SLS-360 UV 36x1W Floor
technical overview
Power supply: 100-240 V AC, 50/60 Hz
DMX channels: 2
DMX connection: 3-pin XLR
Sound-control: via built-in microphone
LED type: 1 W UV
LED number: 36
Beam angle: 30°
Dimensions (L x W x H): 70 x 260 x 245 mm
Ecodesign regulation: Yes
Special product: Not designed for household room illumination
Purpose: Show effect lighting
IP classification: IP20
Beam angle: 30°
Cooling fan: Yes
Weight: 1 kg
Lamp type: LED lamp
Power consumption: 35 W
Laser class: Without laser
Height: 24,5 cm
Depth: 7 cm
Width: 26 cm
Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M)
LED: 36 x high-power 1 W UV
DMX channels: 2
Power supply: 110-240 V AC, 50/60 Hz
main features
DMX controlled UV spot with 36 x 1 W UV LED
-Equipped with 36 x 1 W UV LED
-Perfect for decorative and illumination purposes
-Flat housing form requires minimal space when rigging
-Standing or hanging installation possible
-Second mounting bracket for safe standing installation
-Locking possibility at the mounting brackets
-Comfortable addressing and setting via control panel with LED display
-Functions: dimming, sound-control, strobe effects, Master/Slave
-Operable in stand-alone mode or via DMX
-DMX512 control via any commercial DMX-controller (occupies 2 channels)
-Memory function
-Sound-control via built-in microphone
-Master/Slave for parallel operation of several devices
-Switch-mode power supply for operation between 100 and 240 Volts
-Feed-through output allows to power up to 7 devices
-Ready for connection via included IEC power cord with safety power plug
-Case color: Black
-Effect: Strobe effect; UV
-Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M) (provided)
-Power out: 1 x IEC connector (F) mounting version
-Control: Stand-alone; DMX
-LED: 36 x high-power 1 W UV
Connectors
DMX connector types
3pin
Control
control channels, min
2 ch
control channels, max
2 ch
Electrical
power consumption watt, max
1.00 W
AC Volts, min
110 V
AC Volts, max
240 V
AC Frequency, min
50 Hz
AC Frequency, max
60 Hz
IP rating
20
power input connector
IEC-60320 C13/C14
cooling
active
Mechanical
weight
1.00 kg
width
260.00 mm
height
245.00 mm
length
70.00 mm
Optical
beam angle/zoom, min
30.00 °
beam angle/zoom, max
30.00 °
light source
LED
Number of light sources
36 pcs
wattage per light source
1.00 W

add to list

Collect interesting products in a list and download tender specifications at once

show list

Downloads
Bedienungsanleitung
00114849.pdf
