Info | |
---|---|
order code |
51914174
|
product link | |
EAN |
4026397434842
|
Product Name |
EUROLITE LED IP PAR 36x1W RGB
|
technical overview |
Power supply: 230 V AC, 50 Hz DMX channels: 3/5 DMX connection: 3-pin screw connector Protection grade: IP65 LED number: 36 LED type: 1 W Beam angle: 15° Dimensions (L x W x H): 200 x 240 x 320 mm Ecodesign regulation: Yes Special product: Not designed for household room illumination Purpose: Show effect lighting IP classification: IP65 DMX channels: 3 Weight: 3,75 kg Cooling fan: No, cooling by convection Power consumption: 50 W Lamp type: LED lamp Laser class: Without laser Beam angle: 15° Height: 32 cm Depth: 20 cm Width: 24 cm Power connection: Mains Input Socket (M) 3-pin screw plug connector (M) IP Power supply cord with safety plug (M) LED: 36 x high-power 1 W RGB (homogenous color mix) Power supply: 230 V AC, 50 Hz |
main features |
Weather-proof DMX spot (IP65) with 36 x 1 W LED in red, green and blue -Equipped with 36 x 1 W LED: 12 x red, 12 x green and 12 x blue -3 or 5 DMX channels selectable for numerous applications -Beam angle approximately 15° -Locking possibility at the mounting bracket -Ideal as floor spot via additional bracket -Stepless RGB color change -7 color presets and 4 built-in programs -DMX-controlled operation or stand-alone operation with Master/Slave function -Dimmer and strobe settings via DMX -Suitable for external use (IP65) -Perfect for architectural lighting in public places and buildings -Addressing via control panel with 4-digit LED display -Control via control panel with display or any regular DMX controller -Feed-through output allows to power another device -After every 8 spot the fixtures must have a renewed connection with the power mains -Case color: Black -Effect: Strobe effect -Power connection: Mains Input Socket (M) 3-pin screw plug connector (M) IP Power supply cord with safety plug (M) (provided) -Power out: 1 x 3-pin screw plug connector (F) IP -Control: Stand-alone; DMX -LED: 36 x high-power 1 W RGB (homogenous color mix) |
Connectors | |
DMX connector types |
other
|
Control | |
control channels, min |
3 ch
|
control channels, max |
3 ch
|
Electrical | |
power consumption watt, max |
50.00 W
|
AC Volts, min |
230 V
|
AC Volts, max |
230 V
|
AC Frequency, min |
50 Hz
|
AC Frequency, max |
50 Hz
|
IP rating |
65
|
cooling |
passive
|
Mechanical | |
weight |
3.75 kg
|
width |
240.00 mm
|
height |
320.00 mm
|
length |
200.00 mm
|
Optical | |
beam angle/zoom, min |
15.00 °
|
beam angle/zoom, max |
15.00 °
|
light source |
LED
|
Number of light sources |
36 pcs
|
wattage per light source |
1.00 W
|
RED light source |
yes
|
GREEN light source |
yes
|
BLUE light source |
yes
|
Collect interesting products in a list and download tender specifications at once
Videos |
---|
Downloads |
---|
Bedienungsanleitung |
---|
00072278.pdf |
